The 408 Champion Snatch Block features a swivel hook for wire rope lifting and pulling setups. The hook rotates 360° to help align the block with the direction of pull. Available models shown in the supplied images have marked capacities of 2, 4 and 8 tons.
Product type: Champion snatch block with swivel hook.
Capacity: 2, 4 and 8 ton models are shown in the supplied product images.
Construction: The reference product describes a drop-forged hook and a bronze-bushed sheave. Confirm the construction of each supplied model against its final specification sheet.
Hook movement: 360° swivel, as marked in the product images.
Applications: Wire rope lifting, pulling and load-direction changes in suitable rigging systems. Select the block according to its marked working load and the complete rigging arrangement.
Customization: We accept requests for different block sizes, hook configurations and rope groove dimensions. Final specifications are confirmed before production.
Xintai Lifting Tools Co., Ltd. supplies lifting and rigging equipment for industrial projects. Our team can review the required capacity, wire rope size and connection arrangement to help customers select a standard model or specify a customized block.
Marked Capacity | Size | Overall Length (mm) | Block Width (mm) | Hook Opening (mm) | Groove Width (mm) | Unit Weight (kg) |
2 ton | 3 in | 250 | 75 | 25 | 18 | 2.4 |
4 ton | — | 370 | 110 | 33 | 15 | 5.6 |
8 ton | — | 450 | 150 | 40 | 20 | 12.5 |
8 ton | 8 in | 450 | 200 | 40 | 20 | — |
“—” means the value is not shown in the supplied images. Confirm the final dimensions and marked working load on the product and specification sheet before purchase.
Name: 408 Champion Snatch Block with Swivel Hook
MOQ: 1 piece
Package: Carton + Steel Pallet
Manufacturing Standards: Produce and inspect each model against its approved drawings, material requirements and specified dimensions. ASME B30.26 includes rigging blocks within its scope; compliance of the supplied product must be supported by model-specific documentation.
Testing Standards: Verify the load marking, hook movement, sheave operation and applicable load-test records according to the agreed inspection plan.
Application Standards: Use with a compatible wire rope and within the block’s marked working load limit. Check the full rigging arrangement before use.
Maintenance Standards: Inspect the hook, latch, side plates, sheave and fasteners before use. Clean and lubricate moving parts as required, and remove damaged equipment from service.
