Grade 100 Shortening Clevis Link close left right

Grade 100 Shortening Clevis Link

Grade 100 Shortening Clevis LinkTough Powder Coat Finish4:1 Design FactorProof TestedEmbossed with Grade & SizeDesigned for In-Line Shortening of ChainMust be Used with Grade 100 Connecting LinkSpare Parts Always Available
Introduction
Parameter

Working
Load Limit
(Lbs.)
For
Chain
Size
Dimensions Weight
Ea.
e b a d1 d2 g
2,700 7/32″ 3.31 1.46 1.12 0.71 0.35 0.31 0.66
4,300 9/32″ 4.80 2.13 1.54 0.94 0.47 0.41 1.37
5,700 5/16″ 4.8 2.13 1.54 0.94 0.47 0.41 2.76
8,800 3/8″ 6.26 2.74 1.97 1.22 0.55 0.51 2.76
15,000 1/2″ 7.99 3.62 2.52 1.46 0.71 0.59 5.95
22,600 5/8″ 9.21 4.02 3.15 1.89 0.94 0.79 10.58
Standards

Name: Grade 100 Shortening Clevis Link

Package: Carton + Steel Pallet
