Grade 80 TOSL Chain Sling - Triple Leg w/ Quad Oblong Master Link on Top and Self Locking Hooks on Bottom close left right

Grade 80 TOSL Chain Sling - Triple Leg w/ Quad Oblong Master Link on Top and Self Locking Hooks on Bottom

Grade 80 TOSL Chain Sling – Triple Leg w/ Quad Oblong Master Link on Top and Self Locking Hooks on BottomSling StyleIndividualized Serial NumberChain Size & GradeExact Length of the SlingWorking Load Limit

Introduction

S= Sling Leg
T=Triple Leg
S=Sling Hook (w/latch)
SL=Self Locking (Safety) Hook
F=Foundry Hook
D=Double Leg
Q=Quad Leg
G=Grab Hook
O= Oblong Master Link

The chain sling will be provided with a written certification.
The serial number on the tag will coordinate with the Cert and
your sales order number. This ensures complete traceability.

Parameter
Design Factor1-Leg Sling2-Leg Sling3-Leg & 4-Leg Slings
4:1
Chain Diameter90 Degrees60 Degrees45 Degrees30 Degrees60 Degrees45 Degrees30 Degrees
Load Factor: 1Load Factor: 1.7Load Factor: 1.4Load Factor: 1Load Factor: 2.6Load Factor: 2.1Load Factor: 1.45
7/32″2,1003,6003,0002,1005,5004,4003,200
9/32″3,5006,1004,9003,5009,1007,4005,200
5/16″4,5007,8006,4004,50011,7009,5006,800
3/8″7,10012,30010,0007,10018,40015,10010,600
1/2″12,00020,80017,00012,00031,20025,50018,000
5/8″18,10031,30025,60018,10047,00038,40027,100
3/4″28,30049,00040,00028,30073,50060,00042,400
7/8″34,20059,20048,40034,20088,90072,50051,300
1″47,70082,60067,40047,700123,900101,20071,500
1-1/4″72,300125,200102,20072,300187,800153,400108,500
Standards

Name: Grade 80 TOSL Chain Sling – Triple Leg w/ Quad Oblong Master Link on Top and Self Locking Hooks on Bottom

MOQ: 100 Meters

Package: Carton + Steel Pallet
