Grade 100 Eye Self Locking Hook? Quenched and Tempered Alloy Steel.? At least 25% greater WLL than traditional G80 products.? Manufactured in accordance with EN 1677- 3and ASME B30.26, ASME B30.10.? Certified by DGUV GS-OA-15-05 & DGUV GS-MO-15-05? Proof Load tested at 2.5 times the WLL with certificationfor each batch manufactured.? Design Factor 4:1.? Fatigue rated to 20,000 cycles at 1.5 times the WLL.? Tempering temperature minimum 400°C? Magnaflux crack detection is performed 100% on each batch.
| Reference Number? | Working Load Limit | For Grade 100 Chain in. | Dimensions (inch)Weight lbs. | Weight Ea. | ||||||
| e | h | a | w | w1 | d2 | g | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| WH70 | 5,700 | 9/32-5/16″ | 7.13 | 1.02 | 0.79 | 1.38 | 1.38 | 0.51 | 1.34 | 2.43 |
| WH100 | 8,800 | 3/8″ | 8.58 | 1.18 | 1.14 | 1.65 | 1.57 | 0.63 | 1.77 | 4.41 |
| WH130 | 15,000 | 1/2″ | 10.59 | 1.57 | 1.38 | 1.93 | 1.85 | 0.79 | 2.05 | 8.82 |
| WH160 | 22,600 | 5/8″ | 12.56 | 1.97 | 1.61 | 2.36 | 2.36 | 0.94 | 2.36 | 14.99 |
Name: Grade 100 Eye Self Locking Hook
Package: Carton + Steel Pallet
