Grade 100 Web Sling HookQuenched and Tempered Alloy Steel.At least 25% greater WLL than traditional G80 products.Manufactured in accordance with EN 1677-1 and ASME B30.26Proof Load tested at 2.5 times the WLL withcertification for each batch manufactured.Design Factor 4:1.Fatigue rated to 20,000 cycles at 1.5 times the WLL.Tempering temperature minimum 400°Cgrade 100 Web Sling Hook
| Working Load Limit | Dimensions (inch) | Weight (lbs) | |||||
| lbs* | tons* | H | K | P | T | W | |
|---|---|---|---|---|---|---|---|
| 2,200 | 1 | 0.79 | 3.50 | 0.98 | 0.59 | 1.69 | 1.5 |
| 4,400 | 2 | 1.06 | 4.57 | 1.18 | 0.79 | 2.09 | 3.3 |
| 6,600 | 3 | 1.26 | 4.69 | 1.26 | 1.02 | 2.52 | 5.3 |
Name: Grade 100 Web Sling Hook
Package: Carton + Steel Pallet
