Grade 100 Binder Chain close left right

Grade 100 Binder Chain

Grade 100 Binder ChainGrade 100 Alloy Steel4:1 Design FactorComes fully assembled with hooks on both endsSupplied hooks do not have a cradleDesigned for lashing down NOT overhead lifting

Introduction

Grade 100 Chain was specifically designed to for the rigorous requirements of overhead lifting applications. We have used this premium chain to produce our Grade 100 Binder Chains. Grade 100 Chain has a 20 percent increase in working load limit as compared to a similar size chain in Grade 80. This allows you to reduce the size or number of chains required. Grade 100 binder chains are also referred to as a Tow / Binder, Alloy Log Chain, Grade 10, System 10, Spectrum 10. Grade 100 Chain IS approved for overhead lifting. HOWEVER we do not recommend our Grade 100 Binder/Tow Chain for Overhead lifting. The binder chains are supplied with a clevis grab hook on each end. These hooks do not have a cradle and are designed to fit through the rub rail of a flatbed trailer.

Parameter

Grade of Chain: NACM (National Association of Chain Manufacturers & ASTM (American Society for Test Materials) classify chains in various grades. The higher the grade, the higher the working load limit for the same size of chain.

Working Load Limit (WLL): (rated capacity) Is the maximum working load that should be applied In direct tension to an undamaged straight length of chain.

Proof Test: (manufacturing test force) Is a term designating the minimum tensile force which has been applied to a chain under a constantly increasing force In direct tension during the manufacturing process. These loads are manufacturing integrity tests and shall not be used as criteria for service or design purpose.

Minimum Breaking Force: The minimum force at which the chain during manufacture has been found by testing to break when a constantly increasing force is applied in direct tension. Breaking force values are not guarantees that all chain segments will endure these loads. This test is a manufacturer’s attribute acceptance test and SHALL NOT be used as criteria for service and design purpose.

Overhead Lifting: The process of lifting that would elevate a freely suspended load to such a position that dropping a load would present a possibility of bodily injury or Property damage.

Standards

Name: Grade 100 Binder Chain

MOQ: 100 Meters

Package: Carton + Steel Pallet
